BIS CERTIFICATION FOR THERMOSTAT METAL SHEET AND STRIP
IS 5478:1969

In this competitive scenario, it isn't easy to survive in the market without a standard quality and certified product. BIS license may also be required to sell products in the Indian market.

To get BIS certification and produce a standard quality product, the manufacturer must ensure that their product must follow the specified Indian standard.

Let’s take a closer look at IS 5478:1969 for the thermostat metal sheet and strip.

IS 5478:1969 covers the thermostat metal sheet and strip. This standard specifies the general requirements for thermostat metal in sheet and strip form.

Thermostat metal is a composite material, usually in the form of a sheet or strip, made up of two or more materials of any appropriate nature, metallic, or otherwise, that tend to change curvature when the temperature is changed due to the differing coefficients of linear expansion of the components.

By including material constants such as chemical composition and physical properties, this standard can also be used as a guide in preparing detailed specifications for various specified types of thermostat metals.

The physical properties of a specific type of thermostat metal, such as flexibility, hardness, and electrical resistivity, must conform to the specifications established by the supplier and must be as agreed upon between the purchaser and the supplier.

The bond between the component materials must be strong and complete throughout the entire sheet or strip. The material's surface must be free of cracks, seams, laps, scratches, blisters, rust, and other defects that are detrimental to the material's performance.

The supplier must provide a certificate stating that the material supplied meets the material specification requirements.

TESTS

  • Reverse bend test
  • Flexibility test
  • Hardness test
  • Resistance test
  • Dimension and tolerances

Packing and Marking:

The thermostat metal must be packaged to prevent damage during normal handling and transportation. The entire length and width of the thermostat metal must be marked in accordance with the supplier's own standards.

The ISI mark must be applied to the product, provided that the product so marked meets all of the specification's requirements. The manufacturer must obtain a BIS license from the Bureau of Indian Standards to use a standard mark. The BIS issues a license based on a successful evaluation of the manufacturing infrastructure, quality control, testing capabilities, and manufacturing process.

isi mark

NOTE:

For Detailed Information about the Procedure for BIS ISI Certification, Visit :

  1. Procedure for Domestic Manufacturer
  2. Procedure for Foreign Manufacturer

Conclusion:

If a product falls under the scope of the BIS Conformity Assessment Scheme, All the manufacturers, importers, and foreign entities must obtain BIS ISI Certification. The Bureau may cancel the License if the product fails to meet certification requirements.

Aleph INDIA has been serving the industry as a single-window operator for all product regulatory compliance. We can assist importers or manufacturers in meeting all criteria for importing or selling a product in the Indian market.
